1
Model
MAVERICK
2
Year
2017
3
Trim
MAVERICK
4
Parts Catalog
Gear Box Output Shaft - GBPS - Maverick-Maverick MAX, XMR
5
Parts Diagram
Parts Catalog
Gear Box Output Shaft - GBPS - Maverick Turbo-Maverick MAX Turbo
by
Gear Box and Components - GBPS - Maverick-Maverick MAX, XMR
Gear Box Output Shaft - GBPS - Maverick-Maverick MAX, XMR
36
28
20
16
39
35
38
29
22
18
12
2
2
2
2
34
11
4
9
19
10
23
23
37
7
8
17
17
27
30
26
26
21
31
25
14
24
15
15
5
3
6
33
1>6
Not Available As Spare Parts
XXX
Not Available
2
CENTER PIN 8 X 12
420632010
4,68€ Unit Price incl. VAT
3
Not Available As Spare Parts
XXX
Not Available
4
BALL BEARING
420932816
49,06€ Unit Price incl. VAT
5
BALL BEARING
420932432
420932433
26,36€ Unit Price incl. VAT
6
OIL SEAL
420250452
21,28€ Unit Price incl. VAT
7
FLANGED TORX SCREW M8 X 35
420440861
3,84€ Unit Price incl. VAT
8
PLAIN WASHER
420227937
15,54€ Unit Price incl. VAT
9
Not Available As Spare Parts
XXX
Not Available
9>12
SHIFT SHAFT ASS Y
420620922
111,00€ Unit Price incl. VAT
10
Not Available As Spare Parts
XXX
Not Available
11
Not Available As Spare Parts
XXX
Not Available
12
Not Available As Spare Parts
XXX
Not Available
13>20
SHIFT DRUM ASS Y
420657225
362,00€ Unit Price incl. VAT
13>20
SHIFTING DRUM ASS Y
420657235
362,00€ Unit Price incl. VAT
14
Not Available As Spare Parts
XXX
Not Available
15
Not Available As Spare Parts
XXX
Not Available
16
Not Available As Spare Parts
XXX
Not Available
17
Not Available As Spare Parts
XXX
Not Available
18
Not Available As Spare Parts
XXX
Not Available
19
Not Available As Spare Parts
XXX
Not Available
20
Not Available As Spare Parts
XXX
Not Available
21
Not Available As Spare Parts
XXX
Not Available
22
ALLEN SCREW M6 X 20
420241939
0,82€ Unit Price incl. VAT
23
COUNTERSHAFT
420637426
420637705
440,00€ Unit Price incl. VAT
23
COUNTERSHAFT
420620677
420637707
440,00€ Unit Price incl. VAT
24
OIL SEAL
420831955
32,60€ Unit Price incl. VAT
25
Not Available As Spare Parts
XXX
Not Available
26
Not Available As Spare Parts
XXX
Not Available
27
Not Available As Spare Parts
XXX
Not Available
28
Not Available As Spare Parts
XXX
Not Available
29
Not Available As Spare Parts
XXX
Not Available
30
Not Available As Spare Parts
XXX
Not Available
31
Not Available As Spare Parts
XXX
Not Available
32
SHIFTING SLEEVE KIT
420257673
420257674
151,01€ Unit Price incl. VAT
33
SHIFT FORK
420257606
55,56€ Unit Price incl. VAT
33a
NEEDLE PIN
420832650
8,88€ Unit Price incl. VAT
34
SET SCREW M6 X 8
420841771
4,46€ Unit Price incl. VAT
35
HEX. SCREW M6 X 8
420841580
1,32€ Unit Price incl. VAT
36
FLANGED TORX SCREW M6 X 85
420641228
8,76€ Unit Price incl. VAT
37
FLANGED TORX SCREW M8 X 55
420641213
8,76€ Unit Price incl. VAT
38
FLANGED TORX SCREW M6 X 35
420440274
1,20€ Unit Price incl. VAT
39
FLANGED TORX SCREW M6 X 55
420440702
3,64€ Unit Price incl. VAT

Find the detailed Gear Box Output Shaft - GBPS - Maverick-Maverick MAX, XMR CAN-AM diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original CAN-AM part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
